AP2050DN Access Point
Huawei AP2050DN is the latest-generation gigabit wall plate Access Point (AP) that complies with 802.11ac Wave 2, 2 x 2 MIMO and two spatial streams. It is applicable to environments densely populated with small rooms, such as hotels, student dormitories, hospitals, and offices.
Huawei’s AP2050DN Access Point can be deployed in a variety of ways for reliable storage and power anywhere
- One GE uplink port, four GE downlink ports, and two RJ45 pass-through phone ports (compatible with RJ11)
-
Various installation modes for easy deployment, including ceiling-mounting, wall-mounting, plate-mounting and desk-mounting
- USB port for storage and external power supply
- Supports cloud-based management and enables Huawei Agile Controller-Cloud Manager to manage and operate APs and services on the APs, reducing network O&M costs
| Specifications | AP2050DN |
| Dimensions (H x W x D) | 140 mm x 86 mm x 36 mm |
| Power Input
|
DC: 48V ±5%
PoE power supply: In compliance with IEEE 802.3af/at |
| Maximum Power Consumption | 11.5W
Note: The actual maximum power consumption depends on local laws and regulations |
| Operating Temperature | 0°C to 40°C |
| Antenna Type | Built-in antenna |
| Maximum Number of Users | ≤ 256 |
| Maximum Transmit Power | 2.4G: 21 dBm (combined power)
5G: 20 dBm (combined power) Notes: The actual transmit power depends on local laws and regulations. The AP2050DN uses a 86-type box and applies only to countries and regions that support 86-type boxes |
| MIMO: Spatial Streams | 2 x 2:2 |
| Radio Protocols | 802.11a/b/g/n/ac/ac wave 2 |
| Maximum Rate | 1.267 Gbit/s |
