AP4030DN & AP4130DN Access Points

Huawei’s cost-effective 802.11n/ac AP4030DN and AP4130DN Access Points (APs) provide gigabit access to greatly improve a user’s experience on wireless networks. This series of APs is best suited for small and medium enterprises, airports and stations, sports stadiums, cafés, and entertainment centers.

In compliance with IEEE 802.11ac, the AP4030DN and AP4130DN support 2 x 2 MIMO. The APs offer comprehensive service support capabilities, and feature high reliability, high security, and easy network deployment.

Simplify your Operations and Maintenance (O&M) with automatic AC discovery and configuration, real-time management and maintenance with Huawei’s AP4030DN and AP4130DN APs.

Deploy cost-effective AP4030DN and AP4130DN APs to enable wireless services for airports, sports stadiums, cafés, and entertainment centers

  • High-speed and reliable wireless access services: 1.167 Gbit/s, 2 x 2 MIMO, 2.4 GHz and 5 GHz frequency bands
  • Comprehensive control capabilities: user access control based on user group policies
  • Proven network security: WIDS and WIPS
  • Rich network features: IPv4/IPv6 dual stack
Specifications AP4030DN AP4130DN
Dimensions (H x W x D) 180 mm x 180 mm x 39.5 mm 180 mm x 180 mm x 39.5 mm
Power Input 12V DC ± 10%

PoE: -48V DC (in compliance with IEEE 802.3af/at)

12V DC ± 10%

PoE: -48V DC (in compliance with IEEE 802.3af/at)

Maximum Power Consumption 10.2W 10.2W
Operating Temperature -10°C to 50°C -10°C to 50°C
Antenna Type/Antenna Gain Built-in antenna/2.4 GHz: 4 dBi; 5 GHz: 6 dBi Removable RP-SMA antenna/2.4 GHz: 2.5 dBi; 5 GHz: 4 dBi
Maximum Number of Users ≤ 256 ≤ 256
Maximum Transmit Power 23 dBm (combined power) 23 dBm (combined power)
MIMO: Spatial Streams 2 x 2:2 2 x 2:2
Wireless Protocols 802.11a/b/g/n/ac 802.11a/b/g/n/ac
Highest Rate 1.167 Gbit/s 1.167 Gbit/s
