AP4030TN Access Point
Huawei AP4030TN is a wireless access point in compliance with 802.11ac standards. It supports Software-Defined Radio (SDR) and uses a triple-radio frequency design with each radio frequency supporting 2 x 2 MIMO and two spatial streams. The AP4030TN provides a rate of up to 2 Gbit/s and is applicable to environments such as eClassroom, high-density venues, shopping malls, and supermarkets.
Flexible switching, high link reliability, and external power and storage
- The triple-radio frequency design (one 5G and two 2.4G/5G radio frequencies) supports flexible switching between 2.4 GHz and 5 GHz. SDR allows users to customize radio functions for different applications
- Dual Ethernet interfaces support link aggregation and traffic load balancing to ensure link reliability
- The USB interface is used for external power supply and storage
| Specifications | AP4030TN |
| Dimensions (H x W x D) | 53 mm x 220 mm x 220 mm |
| Power Input | 12V DC ±10%
PoE power supply: in compliance with IEEE 802.3at |
| Maximum Power Consumption | 21.5W (excluding the output power of the USB port)
Note: The actual maximum power consumption depends on local laws and regulations |
| Operating Temperature | –10°C to 45°C |
| Antenna Type | Built-in omni-directional dual-band antenna |
| Maximum Number of Users | ≤ 256 |
| Maximum Transmit Power | 2.4 GHz: 23 dBm (combined power)
5 GHz: 23 dBm (combined power) Notes: The actual transmit power depends on local laws and regulations |
| MIMO: Spatial Streams | 2 x 2:2 |
| Radio Protocols | 802.11a/b/g/n/ac |
| Maximum Rate | 2 Gbit/s |
