AP4050DN-HD Access Point

Huawei AP4050DN-HD is a wireless access point that supports 802.11ac Wave 2, 2 x 2 MIMO, and two spatial streams. The AP4050DN-HD provides a rate of up to 1.267 Gbit/s. It uses built-in high-density smart antennas and is applicable to indoor high-density stadiums.

Features

Reliable wireless access for indoor high-density environments

  • Embedded smart antennas, purpose-built for high-density scenarios, reduce construction costs and mitigate interference between APs
  • Dual Ethernet interfaces support link aggregation and traffic load balancing to ensure link reliability
  • PoE OUT is supported, saving costs in switch ports by 50%
  • Cloud-based AP management using the Agile Controller-Cloud Manager

Specifications

Specifications AP4050DN-HD
Dimensions (H x W x D) 65 mm x 240 mm x 334 mm
Power Input 12V DC ±10%

PoE power: In compliance with IEEE 802.3af/at
Maximum Power Consumption
  • 11.8W (in 802.3af PoE or DC mode)
  • 13.9W (in 802.3at PoE mode, excluding the output power of the PoE OUT port)

Note: The actual maximum power consumption depends on local laws and regulations
Operating Temperature –10°C to 50°C
Antenna Type Built-in high-density smart antennas
Maximum Number of Users ≤ 256
Maximum Transmit Power 2.4 GHz: 22 dBm (combined power)

5 GHz: 22 dBm (combined power)

Notes: The actual transmit power depends on local laws and regulations.
MIMO: Spatial Streams 2 x 2:2 MU/SU-MIMO
Radio Protocols 802.11a/b/g/n/ac/ac wave2
Maximum Rate 1.267 Gbit/s
