AP6510DN-AGN and AP6610DN-AGN 802.11n Outdoor Access Points

Huawei AP6510DN-AGN and AP6610DN-AGN performance-enhanced 802.11n outdoor APs provide dual-band connectivity for wireless throughput up to 600 Mbit/s. Industrial-grade protection includes a dustproof and waterproof hardened metal casing that is high- and low-temperature resistant.

These APs are designed for challenging outdoor or industrial high-demand/density environments, such as pedestrian areas and factories. They also work well in bridge and wireless backhaul applications for wireless harbor, video surveillance, and train or ground vehicle scenarios.

Build a robust, secure, and scalable outdoor WLAN with Huawei AP6x10DN-AGN APs.

Features

Extensive industrial-grade protection ensures secure, reliable, wireless operation in outdoor environments

  • High-speed, reliable wireless access services at 600 Mbit/s (2.4 GHz and 5 GHz radios); 2 x 2 MIMO; 802.11a/b/g/n compatibility
  • Flexible, robust connectivity with Fit or Fat mode operation, IPv4/IPv6 dual stacking, and RJ45 Ethernet uplink with PoE (802.3at-compliant); the AP6610DN-AGN adds an SFP optical uplink
  • Internal 5-kA feeder surge protection and 6-kA or 6-kV surge protection on the Ethernet port plus an internal 20-kA surge protector for the AC input on the AP6610DN-AGN
  • Strong environmental adaptability with fast startup in low temperatures with adaptive bandwidth management and dynamic management of radio interference
  • Enhanced security features include multiple authentication, encryption modes, and security protection; supports unified authentication on the AC or NMS

Specifications

Specifications AP6510DN-AGN AP6610DN-AGN
Dimensions (H x W x D) 255 mm x 255 mm x 83 mm 255 mm x 255 mm x 83 mm
Power Input PoE: in compliance with IEEE 802.3at AC: 90V to 264V
Maximum Power Consumption 25.5W 30W
Operating Temperature −40°C to 60°C −40°C to 60°C
Antenna Type Dual-polarization antenna or common outdoor antenna Dual-polarization antenna or common outdoor antenna
Maximum Number of Users ≤ 256 ≤ 256
Maximum Transmit Power 29 dBm (combined power) 30 dBm (combined power)
MIMO: Spatial Streams 2 x 2:2 2 x 2:2
Radio Protocols 802.11a/b/g/n 802.11a/b/g/n
Highest Rate 600 Mbit/s 600 Mbit/s
