AC6005 Access ControllerAP8050DN & AP8150DN Access Point

Huawei AP8050DN and AP8150DN are the latest-generation 802.11ac wave 2 outdoor Access Points (APs) that support 2 x 2 MU-MIMO and two spatial streams. They are recommended for use in coverage scenarios (for example, high-density stadiums, squares, pedestrian streets, and amusement parks) and bridging scenarios (for example, wireless harbors, data backhaul, video surveillance, and train-to-ground backhaul).

Features

Improved reliability and performance with surge protection, Bluetooth-based application extension, and reduced O&M

  • 802.11ac wave 2 standards compliance, MU-MIMO (2SU-2MU), delivering services simultaneously on 2.4G and 5G radio frequencies; 1.267 Gbit/s for the device
  • Built-in 5 kA surge protectors, reducing network O&M costs
  • Provide 6 kA or 6 kV surge protection capability on an Ethernet interface, and IP67 protection level, meeting industry-level use requirements
  • The AP8150DN can switch from the 2.4 GHz frequency band to the 5 GHz frequency band. When working at dual 5 GHz frequency bands simultaneously, the AP provides a system rate of 1.73 Gbit/s
  • Built-in Bluetooth, allowing for Bluetooth-based application extension

Specifications

Specifications AP8050DN AP8150DN
Dimensions (H x W x D) 100 mm x 220 mm x 220 mm
Power Input PoE power supply: In compliance with IEEE 802.3at
Maximum Power Consumption 18W

Note: The actual maximum power consumption depends on local laws and regulations
Operating Temperature -40°C to 65°C
Antenna Type Built-in antennas External antennas
Maximum Number of Concurrent Users ≤ 256
Maximum Transmit Power 2.4G: 27 dBm (combined power)
5G: 26 dBm (combined power)

Note: The actual transmit power depends on local laws and regulations2.4G: 26 dBm (combined power)
5G: 24 dBm (combined power)

Note: The actual transmit power depends on local laws and regulationsMIMO: Spatial Streams2 x 2:2Radio Protocols802.11a/b/g/n/ac/ac wave 2Maximum Rate1.267 Gbit/s1.73 Gbit/s
