AP8130DN-W Outdoor Access Point
Huawei AP8130DN-W is the latest-generation 802.11ac outdoor Access Point (AP) for use in large coverage scenarios (high-density stadiums, squares, pedestrian streets, and amusement parks) and bridging scenarios (wireless harbors, data backhaul, video surveillance, and train-to-ground backhaul). It features 3 x 3 MIMO and three spatial streams.
Reliable access regardless of power surges and variable temperature
- Complies with 802.11ac Wave 1, supports 2.4 GHz, 4.9 GHz, or 5 GHz on one radio band and 4.9 GHz or 5 GHz on the other
- Built-in 5 kA surge protectors, requiring no external surge protective devices
- Metal shell and heat dissipation design, adapts to a wide temperature range from -40°C to 65°C
- IP67 protection level, meeting industry-level use requirements
| Specifications | AP8130DN-W |
| Dimensions (H x W x D) | 100 mm x 290 mm x 260 mm |
| Power Input | PoE power supply: In compliance with IEEE 802.3at |
| Maximum Power Consumption | 22.4W
Note: The maximum power consumption depends on local laws and regulations |
| Operating Temperature | -40°C to 65°C |
| Antenna Type | Outdoor external antenna |
| Maximum Number of Users | ≤ 256 |
| Maximum Transmit Power | 2.4 GHz: 28 dBm (combined power)
5 GHz: 26 dBm (combined power) Notes: The transmit power depends on local laws and regulations. You can adjust the transmit power from the maximum transmit power to 1 dBm, in steps of 1 dB |
| MIMO: Spatial Streams | 3 x 3:3 |
| Radio Protocols | 802.11a/b/g/n/ac |
| Maximum Rate | 2.6 Gbit/s |
