AR510 Series Agile Gateways

Powerful, rugged Wi-Fi access gateways for bringing high-quality multimedia access to ground transportation vehicles, bus stations, restaurants, billboards, or any fixed indoor or outdoor location.

Dustproof, waterproof, fan-free design meets ISO, European (EN), and Chinese (QC/T) standards for road vehicle shock and vibration resistance. The gateway mounts either horizontally or vertically.

Comprehensive security features, including multiple authentication methods and PKI, provide secure access and defend against malicious attacks. Implements Open Services Platform (OSP) support for customizing services and applications.

Features

Deliver wireless access anywhere in motion with Huawei’s AR510 Series Agile for 3G/LTE communications

  • Dual-band Access Point (AP) supports 2.4 GHz and 5 GHz Wi-Fi access, with multiple 3G LTE upstream interfaces including WCDMA, HSDPA, and HSUPA/HSPA+
  • 2-channel HD playback with high-capacity storage provides an excellent video viewing experience
  • Android-based Open Services Platform (OSP) support enables custom development; GPS support allows value-added applications based on user locations
  • Industrial design for operating in harsh environments and temperatures from –13°F to 140°F (–25°C to 60°C)
  • Compatible with Huawei’s eSight NMS with simplified, visual O&M interfaces

Specifications

Specifications AR511GW-LAV2M3 AR513W-V3M8 AR515CGW-L
Fixed Ports
  • WAN Ports: 2 x GE
  • Video Ports: 2 video ports (HDMI CVBS, or YPbPr), support for 1080p HD video
  • Audio Ports: 2 stereo outputs (1 output; audio power amplifier), 1 stereo input
  • WAN Ports: 2 x GE
  • Video Ports: 2 x HDMI, 1 x VGA
  • Audio Ports: 2 stereo outputs (L/R), 3.5 mm headset jack
  • Hard disk interface: 1 x eSATA
  • LAN Ports: 6 x FE (M12, can be configured as WAN interfaces)
  • Video Ports: 1 video port (CVBS), 1 x VGA
  • Audio Ports: 2 audio outputs, 1 audio input
  • Hard disk interface: 1 x 2.5 inch SATA (pluggable hard disk box)
3G/LTE FDD LTE, compatible with 3G (WCDMA/HSDPA/HSUPA/HSPA+)

Dual SIM cards (one standby)

 – FDD LTE, compatible with 3G (WCDMA/HSDPA/HSUPA/HSPA+)

Dual SIM cards (one standby)
Wi-Fi Dual-band AP (2.4 GHz and 5 GHz), 2 x 2 MIMO, and 802.11a/b/g/n Dual-band AP (2.4 GHz and 5 GHz), 2 x 2 MIMO, and 802.11a/b/g/n Dual-band AP (2.4 GHz and 5 GHz), 3 x 3 MIMO, and 802.11b/g/n/ac
GPS Supported – Supported
Memory 2 GB 2 GB 2 GB
Storage Built-in Flash 4 GB Built-in Flash 4 GB 1 GB
Power Supply Dual DC inputs: 8V to 36V DC inputs: 12V DC inputs: 8V to 36V
Dimensions (H x W x D) 30 mm x 275 mm x 160 mm 30 mm x 275 mm x 160 mm 117 mm x 214 mm x 370 mm
Operating Temperature –10°C to 60°C –10°C to 60°C –25°C to 55°C
