AR530 Series Agile Gateways
Rugged switching routers designed for a broad range of applications — from Smart Grid electric utilities and industrial switching ring networks to video surveillance and various IoT scenarios.
The 530 Gateway provides comprehensive security and management features; flexible FE, SFP, and RS485 interfaces; and integrated data collection features — Advanced Metering Infrastructure (AMI), Power Line Communications (PLC), and Building Energy-efficiency Management System (BEMS) — in a compact enclosure that can be mounted vertically or horizontally.
Meets IP51 rating for dustproof and waterproof operation in a broad range of temperatures and humidity.
Deploy automation solutions in harsh environments with Huawei’s AR530 Series Agile Gateways for cost-effective switching, routing, and data collection
- Integrates routing, switching, and terminal data collection in one compact, easily deployed system for low TCO
- Supports multiple networking topologies, including Huawei’s Smart Ethernet Protection (SEP) to ensure resilient performance in ring networks
- Ruggedized industrial design meets IP51 protection against water and particulate contamination, and electromagnetic interference; meets environmental requirement standards for transformer substations
- Open interfaces enable integration with third-party data collection devices; IEC 62056 standards for interconnections; FE, SFP, IoT, and RS485 connections
| Specifications | AR532 | AR531-2C-H | AR531GPe-U-H |
| L2 Switching Capacity | – | 5.6 Gbit/s | 5.2 Gbit/s |
| Service Forwarding Performance (IMIX) | – | 150 Mbit/s | 150 Mbit/s |
| Fixed Ethernet Ports | 1 x GE/1 x GE Combo | 2 x GE (SFP) + 6 x FE + 2 x FE Combo |
2 x GE (SFP) + 6 x FE |
| RS485 Ports | 2 | 2-channel | 2-channel |
| DI/DO Ports | 2-channel DI/2-channel DO | 2-channel DI | 2-channel DI |
| 3G | • 1 x MiniSIM, SMA Interface, Support • WCDMA/HSDPA/HSUPA/HSPA+: Band 1, Band 8 • GSM/GPRS/EDGE: 850 MHz/900 MHz/1,800 MHz/1,900 MHz |
– | • UMTS/HSDPA (2,100 MHz/900 MHz) • GSM/GPRS/EDGE (850 MHz/900 MHz/1,800 MHz/1,900 MHz) Dual SIM slots, main and backup |
| RF/PLC | RF: 433M/915M RF (optional) PLC: Huawei PLC-IoT |
– | PLC: S-FSK, Huawei Hi-PLC |
| IP Grade | IP51 (IP54 with outdoor cabinet) | IP51 | IP51 |
| Operating Temperature | –25°C to 70°C | –40°C to 70°C | –40°C to 60°C |
| Dimensions (H x W x D) | 290 mm x 180 mm x 95 mm | 88 mm x 220 mm x 250 mm | 88 mm x 220 mm x 250 mm |
