CloudEngine 8800 Series Data Center Switches
Offering 32 x 100 GE, 64 x 40 GE, or 128 x 25 GE/10 GE ports in a single 2U device that delivers exceptional throughput and low latency as a core or aggregation switch for data centers and high-end campus networks.
Combine CE8800 Series Switches with Huawei CE5800, CE6800, CE7800, and CE12800 Switches in a virtualized environment that is easy to manage and optimized for high-bandwidth, server-based data processing and multimedia applications.
Enhance performance, versatility, and reliability with flexible, SDN-ready CE8800 Switches.
Versatile, SDN-ready Ethernet switches with resilient 100 GE/40 GE/25 GE/10 GE ports, ideal for data centers, large-scale enterprise networks, and resilient cloud computing
- The CE8800 can work with a mainstream virtualization platform and function as the high-performance hardware gateway of an overlay network (VXLAN).
- Huawei’s iStack clustering technology boosts reliability and simplifies network management by combining multiple switches into a single logical switch; also supports long-distance stacking.
- Open Programmability System (OPS) provides comprehensive, open APIs for flexible networking, performance monitoring, dynamic configuration, service management, and security policies.
- Zero-Touch Provisioning (ZTP) makes deployment quick and easy, and enables on-demand network customization and automated O&M.
| Item | CE8860-4C-EI | CE8850-32CQ-EI |
| Ports | 4 slots; different cards can be flexibly used in combinations to achieve a maximum of: 32 x 100 GE QSFP28 64 x 40 GE QSFP+ 128 x 25 GE SFP28 128 x 10 GE SFP+ |
32 x 100 GE QSFP28 + 2 x 10 GE SFP+ |
| Switching Capacity | 6.4 Tbit/s | |
| Forwarding Performance | 3,200 Mpps | |
| Airflow Design | Front-to-back or back-to-front | |
| Device Virtualization | iStack | |
| Network Virtualization | M-LAG TRILL VXLAN routing and bridging QinQ access VXLAN BGP-EVPN |
|
| Network Convergence | FCoE DCBX, PFC, and ETS | |
| Programmability | OPS Modules for Ansible released on open source websites |
|
| Traffic Analysis | NetStream sFlow | |
| Power Number | 2 | 2 |
| Power Supply | AC: 1,200W HD: 1,200W | AC: 600W |
| Operating Voltage | Rated voltage range: 100V AC to 240V AC; 50 Hz to 60 Hz Maximum voltage range: 90V DC to 290V AC; 47 Hz to 63 Hz 240V high-voltage DC power voltage range: 188V to 290V DC 380V high-voltage DC rated voltage range: 240V DC to 380V DC 380V high-voltage DC maximum voltage range: 188V DC to 400V DC |
Rated voltage range: 100V AC to 240V AC; 50 Hz to 60 Hz Maximum voltage range: 90V DC to 290V AC; 47 Hz to 63 Hz |
