eA380 Customer Premises Equipment (CPE)
The Huawei eA380 CPE is a Long Term Evolution (LTE) customer-premises equipment (CPEs). As a wireless gateway, the eA380 can be deployed outdoors to provide services such as data collection and video surveillance.
The eA380 supports LTE Release 11/12, providing functions such as data service, Wi-Fi service, security service, local and remote maintenance and management, and data routing.
High-performance gateway using licensed LTE frequencies
- High performance: eA380 is a new-generation CPE, supporting LTE Category 12 in the uplink and LTE Category 13 in the downlink. It also supports 2CC CA, 4 x 4 MIMO, UL 64QAM and other advanced features.
- Rich functions: including 2.4G/5.8G Wi-Fi access, supporting VoIP, L2VPN, soft SIM card, remote WEB management, and other rich functions, to satisfy the needs of the industry customers.
Specification
| Product | eA380-123 | eA380-135 |
| LTE Working frequency band | 2300 to 2400 MHz (Band 40) 2570 to 2620 MHz (Band 38) 2496 to 2690 MHz (Band 41) 2500 to 2570 MHz (Band 7 UL) 2620 to 2690 MHz (Band 7 DL) |
3400 to 3600 MHz (Band 42) 3600 to 3800 MHz (Band 43) |
| Wi-Fi Working frequency band | 2.400 GHz ~ 2.4835 GHz WLAN: IEEE 802.11b/g/n |
|
| External interface | 1 Ethernet interface (RJ45): 10/100/1000Base-TX Ethernet, POE combined
1 USB interface(for local maintenance only) 1 SIM card slot |
|
| Power consumption | <25W when heater works
<9W when heater off |
|
| Power supply | POE (should be powered by CAT-5e cable eight line );
Input AC 100V ~ 240V, output DC 54V / 650mA |
|
| Dimensions (W×D×H) | 258mmx220mmx85mm | |
| Weight | About 1kg (The power supply adapter is not included) | |
| Water and dust proof | IP65 | |
