EchoLife EG8242H ONT
The EchoLife EG8242H is an indoor Optical Network Terminal (ONT) used in Huawei’s FTTH solution. It utilizes GPON technology to provide ultra-broadband access for home and SOHO users. The EG8242H provides four GE ports, two POTS ports, and one CATV port. The EG8242H features high-performance service forwarding capabilities to ensure an excellent user experience with VoIP, Internet, and HD video services. Therefore, the EG8242H provides a perfect terminal solution and future-oriented service supporting capabilities for FTTH deployment.
Plug-and-play capability, Comprehensive Triple Play Service, and energy efficient ultra-broadband access
- Plug-and-play: Configurations are automatically delivered by the Network Management System so on-site commissioning is not required
- Comprehensive Triple Play Service: The ONT provides abundant ports to implement multiple access services, including home network attached storage, Internet access, voice, and video services, providing users with comprehensive triple play service
- Energy wise: SOC chips integrate PON, voice, gateway, and LSW modules, with up to 25% power savings
Specifications
| Specifications | EG8242H |
| Dimensions (H x W x D) | 220 mm x 160 mm x 32 mm |
| Operating Temperature | 0°C to 40°C |
| Operating Humidity | 5% RH to 95% RH (non-condensing) |
| Power Adapter Input | 100V to 240V AC, 50 Hz/60 Hz |
| System Power Supply | 11V to 13V DC, 2A |
| Network-side Ports | GPON |
| User-side Ports | 4 GE + 2 POTS + CATV |
| Indicators | POWER/PON/LOS/LAN/TEL/CATV |
