FusionServer RH1288 V3 Rack Server

FusionServer RH1288 V3 is a standard 1U, 2-socket rack server. It supports Intel® Xeon® E5-2600 v3 and v4 series processors with up to 20 cores per processor, unlocking superior performance for enterprises’ computing-intensive applications. Designed for cloud computing applications and enterprise applications requiring computing and storage resources, RH1288 V3 strikes an optimal balance between performance and density by supporting up to 1 TB memory and 16 TB local storage.

Rely on Huawei’s RH1288 V3 rack server to build a cost-effective, energy-efficient, small-footprint, and high-performance network with simplified management and maintenance.

intel-enHuawei server with Intel® Xeon® processor.
Intel, the Intel logo, Xeon, and Xeon Inside are trademarks or registered trademarks of Intel Corporation in the U.S. and/or other countries.

Features

High-performance, small-footprint 1U rack server helps enterprises effectively tackle space, power consumption, and O&M challenges

  • High density: 2 RH1288 V3 servers can be deployed in a 2U space, doubling the computing density of a conventional 2U rack server and saving up to 50% on space
  • Outstanding computing performance: Runs new-generation Intel® Xeon® E5-2600 v3/v4 series processors and supports up to 1 TB memory, perfectly meeting the needs of memory-intensive application scenarios
  • Flexible local network configuration: Provides two or four GE ports, two 10 GE ports, or two 56 Gbit/s FDR InfiniBand ports without occupying any PCIe slots, improving network availability
  • Simplified O&M: Provides fault diagnosis LEDs on the front panel to display fault codes indicating the server status; can be installed on guide rails or adjustable rails in a rack, facilitating deployment and maintenance

Specifications

Specifications

Processors Intel® Xeon® E5-2600 v3/v4 series processors
Memory 16 DDR4 RDIMMs/LRDIMMs
Internal Storage Hard disk configurations:

  • 8 x 2.5-inch SAS/SATA HDDs or SSDs (4 NVMe SSDs supported by the NVMe model)
  • 4 x 3.5-inch SAS/SATA HDDs

Built-in flash memory:

  • 2 mini-SSD cards (SATADOMs)
  • 2 SD cards
RAID
  • RAID 0, 1, 10, 5, 50, 6, or 60
  • Configured with a supercapacitor for power-off protection for the cache (optional)
  • RAID state transition, configuration memory, self-diagnosis, and web-based remote configuration
LOM Network Ports 2 GE or 4 GE ports, or 2 x 10 GE ports, or 2 x 56 Gbit/s FDR InfiniBand ports
PCIe Expansion Up to 3 PCIe slots
Fan Modules 5 hot-swappable fan modules in N+1 redundancy mode
Power Supply Units 2 hot-swappable PSUs in 1+1 redundancy mode
Management
  • Uses Huawei Hi1710 management chip and independent ports
  • Supports standard management interfaces, such as SNMP and IPMI; provides GUI, remote KVM, virtual media, SOL, Predictive Failure Analysis (PFA), intelligent power supply, remote control, and hardware monitoring
  • Supports Huawei eSight management software and integration with third-party management systems, such as VMware vCenter, Microsoft System Center, and Nagios
Operating Temperature 5ºC to 45ºC (41ºF to 113ºF), ASHRAE Class A3 and A4 compliant
