FusionServer RH5885H V3 Rack Server

Huawei’s FusionServer RH5885H V3 is a next-generation 4U, 4-socket rack server that supports Intel® Xeon® E7 v3 and v4 series processors with up to 96 cores and a 6 TB memory capacity. It is ideal for mission-critical applications, such as databases, Enterprise Resource Planning (ERP), Business Intelligence (BI) analytics, Big Data, and virtualization.

Get high reliability and better performance with Huawei’s RH5885H V3 rack server.

intel-enHuawei server with Intel® Xeon® processor.
Intel, the Intel logo, Xeon, and Xeon Inside are trademarks or registered trademarks of Intel Corporation in the U.S. and/or other countries.

Features

A 4-socket rack server that delivers rock-solid reliability for mission-critical applications

  • High stability and reliability: Supports 53 Reliability, Availability, and Serviceability (RAS) features, including memory mirroring, memory sparing, and Predictive Failure Analysis (PFA). Key components support hot swap and allow maintenance to be performed without opening the chassis cover
  • Excellent performance: Supports Intel® Xeon® E7 v3 and v4 series processors with up to 96 cores and a maximum memory capacity of 6 TB, turbo-charging the performance of mission-critical applications
  • Flexible expansion: Supports up to 17 PCIe slots (one for RAID) and 23 2.5-inch internal hard disks
  • Simplified maintenance: Engineered with a modular design, supports tool-free maintenance, and provides a touchscreen LCD fault diagnosis panel

Specifications

Specifications

Processors Intel® Xeon® E7-4800 v3/v4 or E7-8800 v3/v4 series processors
Memory 96 DIMMs
Internal Storage 8 or 23 x 2.5-inch SAS/SATA HDDs or SSDs, or 8 x 2.5-inch SAS/SATA HDDs + 4 x 2.5-inch NVMes
RAID
  • RAID 0, 1, 10, 5, 50, 6, or 60
  • Configured with a supercapacitor or Battery Backup Unit (BBU) for power-off protection (optional)
LOM Network Ports 2 GE or 4 GE ports, or 2 x 10 GE ports
PCIe Expansion Up to 17 PCIe slots (including one for RAID)
Fan Modules 5 hot-swappable fan modules in N+1 redundancy mode
Power Supply Units Hot-swappable PSUs in 1+1 or 2+2 redundancy mode
Management
  • Provides independent ports; supports standard management interfaces, such as SNMP and IPMI; provides GUI, remote KVM, virtual media, SOL, Predictive Failure Analysis (PFA), intelligent power supply, remote control, and hardware monitoring
  • Supports Huawei eSight management software and integration with third-party management systems, such as VMware vCenter, Microsoft System Center, and Nagios
Operating Temperature 5ºC to 40ºC (41ºF to 104ºF), ASHRAE Class A3 compliant
