FusionServer X6000 High-Density Server

Huawei FusionServer X6000 is a high-density server that Huawei developed for data center scale-out architecture. With an optimized density design, the X6000 improves data center space utilization and investment efficiency, and is ideal for service scenarios such as cloud computing, web applications, and High-Performance Computing (HPC).

intel-enHuawei server with Intel® Xeon® processor.
Intel, the Intel logo, Xeon, and Xeon Inside are trademarks or registered trademarks of Intel Corporation in the U.S. and/or other countries.

Features

High density, all NVMe SSD storage, and easy maintenance

  • Provides computing density twice that of a conventional 1U rack server, maximizing space utilization in the equipment room
  • Accommodates four compute nodes in a 2U chassis with up to twenty-four 2.5-inch NVMe SSDs
  • Provides a unified management port for managing the entire chassis and all nodes, enabling easier deployment and maintenance
  • Adopts a modular design and hot-swappable key components such as hard disks, fan modules, and Power Supply Units (PSUs), greatly improving O&M efficiency

Specifications

Specifications

Form Factor 2U multi-node server
Server Nodes 4 half-width server nodes
Power Supply Units 2 hot-swappable 1,500W AC PSUs in 1+1 redundancy mode
Fan Modules 4 hot-swappable fan modules in N+1 redundancy mode
Power Supply 110V to 220V AC
Operating Temperature 5ºC to 35ºC (41ºF to 95ºF)
Certifications CE, UL, FCC, CCC, VCCI, and RoHS
Dimensions (H x W x D) 86.1 mm x 436 mm x 805 mm (3.39 in. x 17.17 in. x 31.69 in.)

Note: Holding rails and cable racks are required to implement fan module hot-swap
