FusionServer XH321 V3 Server Node

The XH321 V3 is a next-generation half-width 2-socket server node for the Huawei X6000 high-density server. Powered by Intel® Xeon® E5-2600 v3/v4 series processors, it supports sixteen DDR4 DIMMs and is ideal for server applications, such as cloud computing, web applications, and HPC.

intel-enHuawei server with Intel® Xeon® processor.
Intel, the Intel logo, Xeon, and Xeon Inside are trademarks or registered trademarks of Intel Corporation in the U.S. and/or other countries.

Features

High performance and all NVMe SSD storage

  • Supports Intel® Xeon® E5-2600 v3/v4 series processors with each supporting up to twenty-two cores and 55 MB L3 cache capacity
  • Supports up to six 2.5-inch NVMe SSDs and delivers an ultra-high 4.8 million IOPS, significantly improving storage performance
  • Adopts a modular design; provides pluggable modules for quicker deployment, easier maintenance, and shorter service rollout time

Specifications

Specifications

Form Factor Half-width server node
Processors 1/2 Intel® Xeon® E5-2600 v3/v4 series processors
Memory 16 DDR4 DIMMs
Internal Storage 6 x 2.5-inch SATA/SAS HDDs or NVMe/SAS/SATA SSDs
LOM Network Ports 2 GE or 2 GE + 2 x 10 GE
Management Supports SNMP and IPMI. Provides virtual KVM, virtual media, SOL, remote control, hardware monitoring, and intelligent power supply. Adopts the power capping technology and independent management network ports, and supports NC-SI.
Operating Systems Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, CentOS, Citrix XenServer, and Vmware ESXi
Operating Temperature 5ºC to 35ºC (41ºF to 95ºF)
Certifications CE, UL, FCC, CCC, VCCI, and RoHS
Dimensions (H x W x D) 40.5 mm x 177.9 mm x 545.5 mm (1.59 in. x 7.00 in. x 21.48 in.)
Form Factor Half-width server node

Note: The operating systems supported are subject to the compatibility table. When the processor power exceeds 120W, the highest operating temperature that the node supports is 35ºC (95ºF)
