iBMC, Server Intelligent Management System

The core of server management, iBMC, uses the Hi1710 BMC chip developed by Huawei to provide refined management and control for servers. iBMC adopts multiple innovative technologies and maximizes RAS features — all to improve server reliability, availability, and serviceability.

Specifications

Specifications

Specifications iMana iBMC
Management Chip ST SPEAR 310 Huawei Hi1710
400 MB, ARM9

400 MIPS

 800 MB, ARM11

2,000 DMIPS
Management Interface IPMI 1.5/2.0, SNMPv1/v2c/v3, CLI, and HTTPS
Remote Maintenance Interface KVM 8-bit, virtual media, and SOL KVM 32-bit true color, virtual media, and SOL
Diagnosis FDM (MCE fault processing system), black box, breakdown screenshots and videos
Security Management LDAP domain member management and customized account security policy
Power Control Remote power control, NMI, power capping, dynamic energy savings, and active/standby PSUs
Supported Servers FusionServer V2 series servers, RH5885 V3 and RH5885H V3 servers FusionServer V3 series servers, RH1288A V2 and RH2288A V2 servers
