S5730-SI Series Standard Gigabit Ethernet Switches

The S5730-SI series switches (S5730-SI for short) are next-generation standard gigabit Layer 3 Ethernet switches. They can be used as an access or aggregation switch on a campus network or as an access switch in a data center.

The S5730-SI series switches provide flexible full gigabit access and cost-effective fixed GE/10 GE uplink ports. Meanwhile, the S5730-SI can provide 4 x 40 GE uplink ports with an interface card.

The S5730-SI supports simplified Operations and Maintenance (O&M), intelligent Stack (iStack), flexible Ethernet networking. It also provides enhanced Layer 3 features and mature IPv6 features.

Features

Full gigabit access, GE/10 GE/40 GE uplink ports, power supply backup, and SVF for next-generation switching

  • Provide flexible full gigabit access, cost-effective fixed GE/10 GE uplink ports, and 4 x 40 GE uplink ports with an interface card
  • Support 1+1 backup of power supplies and a mix of AC and DC power supplies
  • Support Super Virtual Fabric (SVF) and can function as a client. SVF virtualizes the campus network architecture of ‘Core/Aggregation Switches + Access Switches + APs’ into a single device for simple management, and supports plug-and-play for easy deployment and simplified O&M

Specifications

Item S5730-48C-SI-AC S5730-48C-PWR-SI-AC S5730-68C-SI-AC S5730-68C-PWR-SI-AC
S5730-68C-PWR-SI
Switching Capacity 680 Gbit/s
Forwarding Performance 444 Mpps 444 Mpps 420 Mpps 420 Mpps
Fixed Ports 24 x 10/100/1,000 Base-T, 8 x 10 Gig SFP+ 24 x 10/100/1,000 Base-T, 8 x 10 Gig SFP+ 48 x 10/100/1,000 Base-T, 4 x 10 Gig SFP+ 48 x 10/100/1,000 Base-T, 4 x 10 Gig SFP+
Extended Slot One extended slot that supports an interface card: 4 x 40 GE QSFP+ interface card
MAC Address Table IEEE 802.1d compliance
32K
MAC address learning and aging
Static, dynamic, and blackhole MAC address entries
Packet filtering based on source MAC addresses
VLAN Features 4K VLANs
Guest VLAN and voice VLAN
GVRP
MUX VLAN
VLAN assignment based on MAC addresses, protocols, IP subnets, policies, and ports
1:1 and N:1 VLAN mapping
IPv4 Routing Static route, RIPv1/v2, RIPng, OSPF, OSPFv3, ECMP, IS-IS, IS-ISv6, BGP, BGP4+, VRRP, and VRRP6
IPv6 Features Neighbor Discovery (ND)
Path MTU (PMTU)
IPv6 ping, IPv6 tracert, and IPv6 Telnet
6to4 tunnel, ISATAP tunnel, and manually configured tunnel
ACLs based on the source IPv6 address, destination IPv6 address, Layer 4 ports, or protocol type
Super Virtual Fabric (SVF) Plug-and-play SVF client
Automatic software and patch loading to clients
One-click and automatic delivery of service configurations
Independent client running
