S9700 Series Terabit Routing Switches
High-performance terabit switches for service aggregation in next-generation data centers, excellent core switches in large campus networks. S9700 switches become fully programmable agile switches with a Huawei agile card upgrade.
S9700 Switches provide L2/L3 switching and rich network services such as MPLS VPN, hardware IPv6, cloud desktop, video conferencing, and wireless communications. Non-stop forwarding, hardware OAM/BFD, ring network protection, and in-service software upgrades maximize uptime availability and reduce Total Cost of Ownership (TCO).
Huawei S9700 Terabit Routing Switches are an excellent choice for stable 100 GE networking.
Future-proof your network with scalable Huawei S9700 Terabit Switches for data centers and large-scale enterprise campus networks
- Super Virtual Fabric (SVF) technology virtualizes fixed switches into line cards and APs into ports, transforming a physical network of core, aggregation and access switches, and APs, into a “super switch” to simplify network management
- Cluster Switch System (CSS) virtualizes multiple physical switches into one logical device to provide higher reliability, switching efficiency, and flexibility, as well as simplified management
- Upgrades to a SDN-ready agile switch with an agile card, equipped with Huawei’s exclusive Ethernet Network Processor (ENP) and Packet Conservation Algorithm for Internet (iPCA) that measures network quality in real time by adding marks on service packets
- Supports board upgrade to provide native wireless ACs
Specifications
| Specifications | S9703 | S9706 | S9712 | ||
| Switching Capacity | 2.88 Tbit/s or 5.76 Tbit/s | 6.72 Tbit/s or 14.72 Tbit/s | 8.64 Tbit/s or 18.56 Tbit/s | ||
| Packet Forwarding Rate | 2,160 Mpps | 2,880 Mpps or 5,040 Mpps | 3,840 Mpps or 6,480 Mpps | ||
| Service Slots | 3 | 6 | 12 | ||
| Wireless Network Management | Native AC
AP access control, AP region management, and AP profile management Radio profile management, unified static configuration, and centralized dynamic management Basic WLAN services, QoS, security, and user management |
||||
| User Management | Unified management of wired and wireless users
802.1x, MAC, and Portal authentication Charging based on traffic volume and online duration User authorization based on user groups, domains, and time ranges |
||||
| iPCA | Adds marks on service packets to measure the number of lost packets and packet loss ratios in real time
Measures the number of lost packets and packet loss ratios at the network and device levels on Layer 2 and Layer 3 networks |
||||
| SVF 2.0 | Up to 2K clients (access switches and APs) virtualized into a single device
2-level AS structure Unified management on Huawei and non-Huawei devices |
||||
| OpenFlow | Supports multiple controllers
Supports multi-level flow tables Supports group tables Supports meter tables Complies with OpenFlow 1.3 standards |
||||
| Interoperability | VLAN-based Spanning Tree (VBST) (interoperating with PVST, PVST+, and RPVST)
Link-type Negotiation Protocol (LNP) (similar to DTP) VLAN Central Management Protocol (VCMP) (similar to VTP) For detailed interoperability certifications and test reports |
||||
