SmartAX MA567x Series ONUs
Resilient Optical Networking Units (ONUs) designed for small or home office environments and small-to-medium sized enterprises. Connect upstream to OLTs with Gbit/s Passive Optical Network (GPON) or GE cable; support high-speed broadband, POTS, fax and video surveillance applications.
Highly integrated for efficiency, flexibility, and easy O&M, SmartAX MA567x Series ONUs are designed with comprehensive security features and protection against unauthorized access and DoS attacks.
Compact enclosure installs easily in vertical or horizontal orientation on a wall, table, or in a cabinet, making it suitable for any indoor environment.
Deliver multiple broadband, POTS and high-bandwidth multimedia services with Huawei’s SmartAX MA567x Series ONUs for SOHO and small business users
- Support for multiple services provides integrated access: Provides users with access to a variety of services, such as GE-to-desk, POTS, fax, and video surveillance
- Secure gateway functions with robust performance: Ensures reliable and secure applications; supports configurations for anti-DoS attacks, packet filtering based on MAC addresses, IP addresses or Uniform Resource Locator (URL) addresses, firewall and ONU access control rules
- Easy Operation, Administration, and Maintenance (OAM): MA567x Series ONUs support TR-069, ONU Management and Control Interface (OMCI), and OAM management modes. With this flexibility, terminal services can be managed without deploying additional IP networks
Specifications
| Specifications | MA5671 (Metal) | MA5671 (Desktop） | MA5671 (PoE) | MA5672 |
| Dimensions (H x W x D) | 27 mm x 134 mm x 115 mm | 4 GE: 28 mm x 175 mm x 138 mm 1 GE: 27 mm x 90 mm x 82 mm |
42 mm x 190 mm x 140 mm | 43.6 mm x 250 mm x 180 mm |
| Operating Environment |
–40°C to 55°C 5% RH to 95% RH |
0°C to 40°C 5% RH to 95% RH |
0°C to 40°C 5% RH to 95% RH |
–40°C to 55°C 5% RH to 95% RH |
| Power | DC: 12V AC: 220V |
4 GE: Chinese standard: 12V DC, 1A British/European standard: 12V DC, 1A American standard: 12V DC, 2A 1 GE: Chinese/European standard: 12V DC, 0.5A British standard: 12V DC, 1A American/Australia standard: 12V DC, 2A |
DC: 12V, 5A | AC: 90V to 300V DC (backup): 12V |
| Network-side Ports | GPON | GPON | GPON (SC/APC) | GPON |
| User-side Ports | 4 GE | 4 GE or 1 GE |
4 GE, PoE
|
4 GE + 8 POTS
|
|
Surge Protection
|
Power port: 6 kV GE: 4 kV |
Power port: 6 kV GE: 4 kV |
Power port: 6 kV
GE: 4 kV |
Power port: 6 kV GE: 4 kV POTS: 4 kV |
