USG6600 Next-Generation Firewall

The USG6600 provides unified network security for large- and medium-size enterprises, organizations, and data centers.

Integrated firewall, VPN, intrusion prevention, antivirus, and data leakage prevention deliver high-performance protection. Identifies more than 6,300+ applications and analyzes intranet service traffic across six dimensions, automatically generating security policy suggestions.

Optimize security management and boost application-layer protection with the USG6600 Series Firewall.

USG6600 is certified by ICSA Labs in Firewall, IPS, IPSec, SSL VPN and AV categories, is certified at CC EAL4+ level, and earned the Recommended Rating from NSS Labs.

Service provisioning implements comprehensive, efficient network security protection for large- and medium-size enterprises with Huawei’s next-generation firewall

  • Six-dimensional access control, identification for 6,300+ applications, and fine-grained application control and acceleration
  • Easy, quick policy deployment, intelligent optimization, and security policy simplification reduce TCO by 30%
  • Comprehensive unified protection, threat detection over SSL-encrypted traffic, and data leakage prevention protect next-generation enterprise networks
  • Dedicated software and hardware design deliver high-performance security protection
Model USG6620/6630 USG6650/6660/6670/6680
Dimensions (H x W x D) 44.4 mm x 442 mm x 421 mm 130.5 mm x 442 mm x 470 mm
Fixed Interfaces 8 x GE (RJ45) + 4 x GE (SFP) USG6650/USG6660: 2 x 10 GE (SFP+) + 8 x GE (RJ45) + 8 x GE (SFP)

USG6670/USG6680: 4 x 10 GE (SFP+) + 16 x GE (RJ45) + 8 x GE (SFP)

USB2.0 Port 2 x USB Ports 2 x USB Ports
Expansion Slot 2 WSIC* USG6650/USG6660: 6 WSIC

USG6670: 5 WSIC

USG6680: (AC) 5 WSIC; (DC) 3 WSIC

Expansion I/O WSIC: 2 x 10 GE (SFP+) + 8 x GE (RJ45), 8 x GE (RJ45), 8 x GE (SFP), 4 x GE (RJ45) BYPASS WSIC: 2 x 10 GE (SFP+) + 8 x GE (RJ45), 8 x GE (RJ45), 8 x GE (SFP), 4 x GE (RJ45) BYPASS
Local Storage Optional: Supports a 300 GB or 600 GB hard disk (the hard disk is hot-swappable, but the hard disk card is not) Optional: Supports 300 GB or 600 GB hard disks (RAID1 and hot-swappable)
AC Power Supply 100V to 240V, 50 Hz/60 Hz 100V to 240V, 50 Hz/60 Hz
DC Power Supply NA USG6650: NA

USG6660/USG6670/USG6680: –48V to –60V

Power Supplies Single 170W AC power supply; optional dual AC power supplies USG6650: Dual AC Power Supply

USG6660/USG6670/USG6680: Dual AC or dual DC power supplies
